RL06 Compact Wheel Loader
RL06Catalogue ref. P078
A compact articulated wheel loader for loading and moving materials on construction sites, farms and municipal projects. The supplied specification lists a Kubota D1105 engine and a 300 kg rated safe load.
Operating weight1725 kg (3802 lb)
Bucket capacity0.23 m³ (8.1 ft³)
Rated load (safe load)300 kg (661 lb)
Manufacturer / catalogue attributionRIPPA
Share the quantity, destination and required configuration for a tailored quotation.
Specifications
| Operating weight | 1725 kg (3802 lb) |
|---|---|
| Bucket capacity | 0.23 m³ (8.1 ft³) |
| Rated load (safe load) | 300 kg (661 lb) |
| Maximum load | 600 kg (1322 lb) |
| Maximum dumping height | 2060 mm (81.1 in) |
| Transport width | 1150 mm (45.3 in) |
| Transport height | 2300 mm (90.6 in) |
| Engine model | D1105 |
| Maximum engine power | 18.2 kW |
| Maximum engine speed | 3000 rpm |
| Travel speed | 0 – 8 km/h |
| Turning radius | 2400 mm (94.5 in) |
| Length with bucket | 3650 mm (143.8 in) |
| Fuel tank capacity | 15 L |
| Working hydraulic pressure | 20 MPa |
Specifications are taken from manufacturer materials. Confirm the exact model, options and destination requirements before ordering.
